MONITOUCH Smart Editor

Model list

Model Product Note
SMED-DVD MONITOUCH Smart Editor
Single license
SMED-DVD-L□□ *1 MONITOUCH Smart Editor
Multiple license
SMED-DVD-SL MONITOUCH Smart Editor
Site license		 Unlimited number of licenses per worksite
SMED-DVD-VUP MONITOUCH Smart Editor
DVD for Version upgrade		 Version upgrade disc (License not included) *2
  • *1 “□” indicates the number of licenses. The price varies depending on the number of licenses. For details, please contact your sales representative or Hakko Electronics.
  • *2 The update module is also downloadable from our website free of charge.

System Requirements

PC PC/AT compatible computer running Windows
OS* Windows 10 (32bit, 64bit)
Windows 11 (64bit)
CPU Windows 10: Intel Core 2 Duo 2GHz or higher recommended
Windows 11: 2 cores or higher (64 bit) or System on a Chip (SoC)
Memory 8GB or more recommended
Hard disk When installed: 5.0 GB or more
Disk drive DVD-ROM drive
Display 1920×1080 (Full HD) or greater
Others · Microsoft .NET Framework 4.0 or higher
· Visual Studio 2015-2022 Visual C++
Redistributable packages
(Automatically installed upon installation, if missing)

*Administrator privileges are required for installation.

It is not possible to edit the V7 series and previous models with Smart Editor.

For the V7 series and previous models, screen data editing is possible with the separate configuration software V-SFT-5.
